Iron Man 3 FS3D BluRay 1080p48 x264 AAC5.1
Presented in full resolution, frame-sequential 3D (FS3D). FS3D provides a higher quality per MB than the common Full-SBS or Full-OU formats. If your display can support FS3D, you should prefer it. Most LG passive 3DTV's support it and it's supported on VR platforms using the newest version of 4XVR!
If your display doesn't support this file, you can convert it to SBS or OU without re-processing using the method below.
Frame-sequential 3D vs Bluray
Full-SBS vs Bluray
Half-SBS vs Bluray
Code:
Format : AVC
Format/Info : Advanced Video Codec
Format profile : High@L4.2
Count of views : 2
MultiView_Layout : Both Eyes laced in one block (left eye first)
Format settings : CABAC / 4 Ref Frames
Format settings, CABAC : Yes
Format settings, Reference frames : 4 frames
Codec ID : V_MPEG4/ISO/AVC
Duration : 2 h 10 min
Width : 1 920 pixels
Height : 1 080 pixels
Display aspect ratio : 16:9
Frame rate mode : Constant
Frame rate : 47.952 (48000/1001) FPS
Color space : YUV
Chroma subsampling : 4:2:0
Bit depth : 8 bits
Scan type : Progressive
Title : 3D Frame-Sequential (x264 high@L4.2 CRF 19 preset veryslow, tune film)
Writing library : x264 core 164 r3106 eaa68fa
Encoding settings : cabac=1 / ref=4 / deblock=1:-1:-1 / analyse=0x3:0x133 / me=umh / subme=7 / psy=1 / psy_rd=1.00:0.15 / mixed_ref=1 / me_range=24 / chroma_me=1 / trellis=2 / 8x8dct=1 / cqm=0 / deadzone=21,11 / fast_pskip=0 / chroma_qp_offset=-3 / threads=18 / lookahead_threads=4 / sliced_threads=0 / nr=0 / decimate=1 / interlaced=0 / bluray_compat=0 / constrained_intra=0 / bframes=5 / b_pyramid=2 / b_adapt=2 / b_bias=0 / direct=3 / weightb=1 / open_gop=0 / weightp=2 / keyint=480 / keyint_min=47 / scenecut=40 / intra_refresh=0 / rc_lookahead=250 / rc=crf / mbtree=1 / crf=19.0 / qcomp=0.70 / qpmin=0 / qpmax=69 / qpstep=4 / vbv_maxrate=15000 / vbv_bufsize=60000 / crf_max=0.0 / nal_hrd=none / filler=0 / frame-packing=5 / ip_ratio=1.40 / aq=3:0.80
Default : Yes
Forced : No
Color range : Limited
Matrix coefficients : BT.709
Audio
ID : 2
Format : AAC LC
Format/Info : Advanced Audio Codec Low Complexity
Codec ID : A_AAC-2
Duration : 2 h 10 min
Channel(s) : 6 channels
Channel layout : C L R Ls Rs LFE
Sampling rate : 48.0 kHz
Frame rate : 46.875 FPS (1024 SPF)
Compression mode : Lossy
Delay relative to video : 9 ms
Title : English (DTS-HD-Master converted to AAC 5.1 quality 0.5)
Language : English
Default : Yes
Forced : No
Text
ID : 3
Format : PGS
Codec ID : S_HDMV/PGS
Codec ID/Info : Picture based subtitle format used on BDs/HD-DVDs
Title : English 2D (BD SUP)
Language : English
Default : No
Forced : No
If your passive 3D display doesn't support this file and you want to convert to Top/Bottom (best for passive 3DTV!), you can do this in Potplayer. Use Avisynth like this:
If your passive 3D display is 1080p and supports 48/96Hz, use these settings:
Code:
left = selecteven
right = selectodd
left1 = selecteven(separatefields(left))
left2 = selectodd(separatefields(left))
right1 = selectodd(separatefields(right))
right2 = selecteven(separatefields(right))
interleave(stackvertical(left1,right1), stackvertical(left2,right2))
assumeframebased
assumefps(48000/1001.0)
If your passive 3D display is 1080p and doesn't support 48/96Hz, use:
Code:
Stackvertical(Selecteven.spline16resize(1920,540),Selectodd.spline16resize(1920,540))
assumefps(24000/1001.0)
If your display uses battery powered glasses and supports 48/96Hz, convert to Side by Side using:
Code:
potplayer_source()
left = selecteven
right = selectodd
left1 = selecteven(separatecolumns(left,2))
left2 = selectodd(SeparateColumns(left,2))
right1 = selectodd(SeparateColumns(right,2))
right2 = selecteven(separatecolumns(right,2))
interleave(StackHorizontal(left1,right1), StackHorizontal(left2,right2))
assumeframebased
assumefps(48000/1001.0)
If your display uses battery powered glasses and doesn't support 48/96Hz, convert to Side by Side using:
Code:
Stackhorizontal(Selecteven.spline16resize(960,1080),Selectodd.spline16resize(960,1080))
assumefps(24000/1001.0)
To watch in 2D, use:
Code:
selecteven
